| Dimensions (W x D x H) | 280mm x 752mm x 810mm (Front service) |
| Dimensions (W x D x H) | 280mm x 757mm x 810mm (Rear service) |
| Weight (without media) | 72kg |
| Service Access | Front or Rear Access |
| Number of Cassettes | Up to 6 Cassettes |
| Bill count speed | 7 notes/second |
| Acceptable Media Range | Max. 82mm x 172mm Min. 60mm x 120mm |
| Thickness | 0.07 ~ 0.18mm Up to 0.3mm other media* *Certification of other media is required |
| Bill transaction | 60 bills/transaction |
| Bill Retrieval | Yes / Bunch presenter |
| Shutter | Optional |
| Capacities / denominations | Accommodation 370mm New notes 3,000 each cassette (approx.) |
| Reject Bin | In 1st cash cartridge |
| Reject Bill Capacity | Approx. 150 Bills |
| Bill low sensor | Adj. sensor 50~300 notes Default: 100 notes |
| Interface | RS232c |
| Electrical Power Requirements | DC +24V (+10%, -10%) Max 10A Ave. 4A |
| Temperature | Operation: 0°C ~ 40°C Stop State: -5°C ~ 50°C |
| Relative Humidity | Operation: 10% ~ 95% Stop State: 8% ~ 95% |
